The chemical K-2 is available in 3 forms as follows giving the same results. Application
of K-2 Passivation solution is a must after the application of all forms of K-2 chemical in order
to avoid further corrosion and contamination



It is used to clean large fabricated equipments of Stainless steel equipments vessels.
agitators, dryers, dairy machinery, fermentators, internals as well as the external of pipes
by a pressurized spray bottle or pump.



We provide special K-2 paste & K-2 spray for cleaning duplex and super duplex stainless steel.

Pickling And Passivation on DUPLEX AND SUPERDUPLEX Stainless Steel



Passivation Solution

Passivation is a must after every pickling operation process.
Next apply K-2 passivation solution and leave it for 20-25 minutes.
Finally clean the surface thoroughly with water.



HOW TO APPLY K - 2 PASTE

1. First remove oil, dirt etc. with SI 56 degreaser. Add 50 - 75 gm/lit. in water & stir to dissolve. Wipe S.S. surface with cotton cloth or spray or soak for 10 min. Wash with water and allow to dry.
(Steps 1 & 5 can be avoided for K-2 PASTE on weld seam application )



2. K-2 PASTE is applied on weld seam & surrounding areas with a nylon bristled plastic brush OR
K-2 Spray is sprayed on S.S. surface with plastic pressurized spray bottle or pump
OR K-2 Dip is used to dip S.S. components in a plastic tank or circulated in pipeline with pump.
Application Temp. = Between 25 - 35 deg. C .
If temp. is less than more time may be required and if temp. is more than uneven processing may result. So, cool SS equipment by keeping its in shade & not directly under the sun.

3. Keep K-2 product for 10 - 45 minutes depending on contamination & scale. ( K-2 PASTE generally kept for 10 - 30 min. and K-2 Spray generally kept for 30 - 45 min. )

4. Wipe the weld seam lightly with plastic brush or cloth & wash with water thoroughly & allow to dry.
5. Spray or Dip in K-2 Passivation or K-2 Biopassive solution & leave it for 10- 20 minutes. Rinse with water thoroughly.


For Passivating Mirror Bright Buffed / Polished SS Areas,

THE BELOW STEPS WILL NOT AFFECT SHINE OF MIRROR BRIGHT BUFFED / POLISHED SS AREAS AND PROVIDE CONTAMINATION & STERILE PARTICLE FREE PASSIVATED SS SURFACE.
1 First apply K-2 PASTE on weld seam & surrounding areas with a nylon bristled plastic brush. After 10 to 30 min. wipe with cloth or plastic brush & wash with water thoroughly.
( Application of K-2 PASTE ensures that black & red spots do not come on & near weld seams area as generally observed some days after bright buffing. )


2 Complete usual bright buffing / polishing procedure to make surface mirror bright & shiny.
( If SS eqpt. or pipe is already bright buffed or polished then discard Steps 1 & 2 and start directly with Step 3 )

3 Remove oil, dirt, buffing compounds etc. with "SI 56" - sulphur free degreaser.
Add 50 - 75 gm/lit. in water ( 1 kg SI 56 in 15 – 20 Lit. water ) & stir to dissolve. Wipe S.S. surface with cotton cloth or pressurized spray for 2 - 5 min. or soak small parts for 10 min. Wash with water properly.

4 Spray or Dip in K-2 passivation or K-2 Biopassive & leave it for 15 - 25 minutes. Then, rinse with water thoroughly.

"SURFACE INNOVATORS " PROVIDES EQUIPMENTS & ACCESSORIES FOR SAFE, IN-HOUSE PICKLING & PASSIVATION FOR ALL TYPES OF JOBS.

PRODUCT APPROVED BY I.I.T. (BOMBAY) UNDER ASTM – A380
ASTM = American Standards of Testing Materials






  K-2 Pickling Paste
  K-2 Pickling Spray
  K-2 Pickling Dip
  K-2 Pickling Duplo
  K-2 Passivation
  K-2 Carbochem
  K-2 SSA For bulk pickling
  K-2 400 Series
